• Air conditioning, single-zone
• Air vents, rear, heating/cooling (Not available on Regular Cab models.)
• Assist handles front A-pillar mounted for driver and passenger, rear B-pillar mounted
• Audio system, Chevrolet Infotainment 3 Premium system with Google built-in compatibility (select service plan required, terms and limitations apply) including navigation capability, 13.4" diagonal HD color touchscreen, includes multi-touch display, AM/FM stereo, Bluetooth® streaming audio for music and most phones; featuring Wireless Apple CarPlay and Wireless Android Auto capability for compatible phones, advanced voice recognition, in-vehicle apps, personalized profiles for infotainment and vehicle settings
• Chevrolet Connected Access capable (Subject to terms. See onstar.com or dealer for details.)
• Compass, located in instrument cluster
• Cruise control, electronic with set and resume speed, steering wheel-mounted
• Door locks, power
• Exterior Temperature Display located in radio display
• Floor covering, color-keyed carpeting
• Keyless Open and Start
• Mirror, inside rearview, manual tilt
• Seat adjuster, driver 4-way manual
• Seat adjuster, passenger 4-way manual
• Steering column, Tilt-Wheel, manual with wheel locking security feature
• Steering wheel audio controls
• Steering wheel, wrapped
• USB Ports, 2, Charge/Data ports located on instrument panel
• USB ports, rear, dual, charge-only
• Wi-Fi Hotspot capable (Terms and limitations apply. See onstar.com or dealer for details.)
• Window, power front, drivers express up/down
• Window, power front, passenger express down
• Windows, power rear, express down (Not available with Regular Cab models.)

• Air filter, heavy-duty
• Air filtration monitoring
• Auto-locking rear differential
• Brakes, 4-wheel antilock, 4-wheel disc with DURALIFE rotors
• Four wheel drive
• Recovery hooks, front, frame-mounted, Black (Not available with (VLQ) Chrome recovery hooks.)
• Suspension Package
• Trailer brake controller, integrated

• Automatic Emergency Braking
• Daytime Running Lamps with automatic exterior lamp control
• Following Distance Indicator
• Forward Collision Alert
• Front Pedestrian Braking
• OnStar Services capable (See onstar.com for details and limitations. Services vary by model. Service plan required.)
• Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver

ENGINE, DURAMAX 6.6L TURBO-DIESEL V8

• B20-Diesel compatible
• (470 hp [350.5 kW] @ 2800 rpm
• 975 lb-ft of torque [1322 Nm] @ 1600 rpm)

• ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE (470 hp [350.5 kW] @ 2800 rpm 975 lb-ft of torque [1322 Nm] @ 1600 rpm)
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hooks
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Tires - Front All-Terrain
• Tires - Rear All-Terrain
• Automatic Highbeams
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Privacy Glass
• AM/FM Stereo
• Navigation System
• Satellite Radio
• WiFi Hotspot
• Split Bench Seat
• Cloth Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Steering Wheel Audio Controls
• Power Windows
• Keyless Entry
• Cruise Control
• A/C
• Traction Control
• Stability Control
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag Sensor
• Navigation from Telematics
• Driver Restriction Features
• Tire Pressure Monitor

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 730
• Cold Cranking Amps @ 0° F (Primary): 720
• Maximum Alternator Capacity (amps): 170
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Front (lbs): 5200
• Gross Axle Wt Rating - Rear (lbs): 10400
• Curb Weight - Front (lbs): 4306
• Curb Weight - Rear (lbs): 2848
• Gross Vehicle Weight Rating Cap (lbs): 14000
• Gross Combined Wt Rating (lbs): 40000
• Gross Combined Wt Rating (lbs): 26000
• Suspension
• Suspension Type - Front: Short Long Arm Independent
• Suspension Type - Rear: Semi-Elliptic Three-Stage Multi-Leaf Spring
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Front: - TBD -
• Axle Type - Rear: - TBD -
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 51
• Shock Absorber Diameter - Rear (mm): 51
• Stabilizer Bar Diameter - Front (in): 1.38
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14 x 1.6
• Rear Brake Rotor Diam x Thickness (in): 14 x 1.6
• Tires
• Front Tire Order Code: QZT
• Rear Tire Order Code: QZT
• Front Tire Size: LT235/80R17E
• Rear Tire Size: LT235/80R17E
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Wheels
• Front Wheel Size (in): 17 x - TBD -
• Rear Wheel Size (in): 17 x - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 57.5
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Hydroformed Fully-Boxed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 63.5
• Fuel Tank Location: Front & Rear
• Exterior Dimensions
• Wheelbase (in): 177
• Length, Overall (in): 270.25
• Width, Max w/o mirrors (in): 80.84
• Height, Overall (in): 80.1
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): 157
• Cab to Axle (in): 60
• Cab to End of Frame (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): 89.15
• Ground Clearance, Front (in): 8.15
• Ground Clearance, Rear (in): 8.15
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 43.03
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Front Hip Room (in): 61.18
• Second Head Room (in): 40.12
• Second Leg Room (in): 43.4
• Second Shoulder Room (in): 65.3
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: Chevrolet Silverado 3500HD CC
• Body Style: Crew Cab Chassis Cab
• Body Code: ZW9
